FEATURES

VLT G2 d

Visibility

Choose from clear or tinted skins to control the visibility as required for your project

SHGC G d

Solar control​

Options such as Coated and tinted work to control the room temperature.

snow1 d

Thermal insulation

Argon gas with a SuperSpacer are less conductive and work to slow heat transfer for more insulation.

dollar2 d

Energy saving

Insulated Glass Units are naturally more energy efficient than single glazed units due to their solar control and insulation.

SPECIFICATIONS

Float Glass Options

  • Clear
  • Grey
  • Crystal Blue
  • Green

Annealed, toughened or heat strengthened Option of heat soaking

Pyrolytic Low-E Options (4-8mm)

  • EnergyTech™ Clear, Grey
  • SolTech™ Neutral, Grey
  • Evantage™ Clear, Grey
  • Sunergy™ Clear

Laminate Glass Options (6.38-12.38mm)

  • Clear, Cool Blue, Grey, White Translucent
  • ComfortPlus Clear, Green, Grey, Neutral
  • HushLam™ Acoustc

Gap

THICKNESS

6, 8, 10, 12, 14, 16, 20 mm

FILL

  • 100% Air (standard)
  • 90% Argon/10% Air (option)

SPACER

  • Aluminium (standard)
  • Optional SuperSpacer (option)
image 2 1 1

PERFORMANCE

A few example glass make-ups shown below. Please contact Glassworks if you require data for a specific make-up that is not represented here.

table1
Light TransmissionReflectanceSolar Heat GainU-Value
SolTech™ Clear IGU
6mm SolTech Clear
12mm Air
6mm Clear
56%12%0.451.8
EnerTech™ Clear IGU
6mm EnerTech Clear
12mm Air
6mm Clear
72%17%0.622.6
EnerTech™ Grey IGU
6mm EnerTech Grey
12mm Air
6mm Clear
35%1%0.391.9
Sunergy™ Clear IGU
6mm Sunergy Clear 12mm Argon 6mm Clear60%12%47%2.5

Centre of glass calculated using LBNL Window 7.3 based on NFRC 100 environmental conditions
