FEATURES
Solar control
LoE-452® blocks harshness of the sun with a low Solar Heat Gain Coefficient (SHGC) of 0.22 on Clear compared with 0.62 of regular low-E double glazed.
Thermal insulation
When room temperature falls below 11 degrees there is the risk of thermal discomfort inside the room. It has a low U-Value of just 1.34 compared to 1.6 of regular low-E double glazed.
Easy-clean coating
LoE-452® comes standard with Neat, a titanium dioxide layer which harnesses the sun’s rays to loosen dirt so the rain can wash it away with minimal streaks.
Energy saving
At the top of its game in terms of passive design, LoE-452® boasts exceptional solar gain coupled with outstanding insulating capabilities for less energy consumption.
High visibility
LoE-452® achieves a Visible Light Transmission (VLT) figure of 50% in certain IGU make ups, above the desired standard for commercial projects, unlike tinted glass.
Fade protection
LoE-452® blocks 99% of the sun’s damaging UV rays, a leading cause of fading.
SPECIFICATIONS
Glass Options
- Available on Clear glass
Glazing options
- Double glazed in an Insulated Glass Unit (IGU) on surface 2
- Can be paired up with LoE-i89 on surface 4 for unprecedented performance
APPLICATIONS
A clear quad silver low-E with a subtle grey tinge and the next level of performance makes LoE-452 the superior option for solar control and light balance. In fact it boasts an LSG (Light to Solar Gain) of 2.33, matched only by LoĒ³-366®, only LoE-452 has a lower SHGC which gives it added performance. Due to its outstanding solar control, we recommend it for both commercial and residential applications in predominently warm climates or western facing elevations in mixed climates.
Commercial applications:
- Education facilities
- Accommodation
- Public spaces
- Hospitality
- Office buildings
- Healthcare
- Green Star projects
Residential applications:
- High-end residential
- Multi-res
- High energy-rated homes
PERFORMANCE
A few example glass make-ups shown below. Please contact Glassworks if you require data for a specific make-up that is not represented here.
| Light Transmission | Solar Heat Gain | U-Value | UV Transmittance | |
|---|---|---|---|---|
| Typical low-E IGU | ||||
| 6mm Clear Low-E 12mm Argon 6mm clear | 73% | 0.67 | 1.62 | 35% |
| LoĒ-452® IGU | ||||
| 6mm LoĒ-452® Clear 12mm Argon 6mm clear | 52% | 0.22 | 1.35 | 1% |
| LoĒ³-366® (surface 2) With LoĒ³-i89 (surface 4) | ||||
| 4mm LoĒ-452® Clear 12mm Argon 4mm LoĒ³-i89 | 52% | 0.22 | 1.11 | 1% |
Centre of glass calculated using LBNL Window 7.3 based on NFRC 100 environmental conditions
